OFC Crimp Sleeves 4.0 mm²

Item-No.:	Size:	Unit:
40105	1,5 mm²	40 pcs
40109	2,5 mm²	40 pcs
40111	4,0 mm²	40 pcs
40113	6,0 mm²	20 pcs
40118	10,0 mm²	20 pcs
40119	16,0 mm²	20 pcs
40122	25,0 mm²	10 pcs
40124	35,0 mm²	10 pcs
40126	50,0 mm²	10 pcs

Item-No.:

Size:

Unit:

40105

1,5 mm²

40 pcs

40109

2,5 mm²

40 pcs

40111

4,0 mm²

40 pcs

40113

6,0 mm²

20 pcs

40118

10,0 mm²

20 pcs

40119

16,0 mm²

20 pcs

40122

25,0 mm²

10 pcs

40124

35,0 mm²

10 pcs

40126

50,0 mm²

10 pcs

OFC crimp sleeves

For professional routing of cable ends

Longterm corrosion protection of the fine strands of high-end cables

Prevents kinking and breaking of single strands

Prevents short circuits as no single strands can splice

Isolation: PVC black

For a perfect conductivity

Material: OFC copper

Finishing: 24 carat real gold-plated

Sizes: 1.5 - 50.0 mm²

VIABLUE™ crimp sleeves size chart
Size	AWG	L1	L2	D1	D2
1.5 mm²	16	17.0 mm	9.5 mm	3.2 mm	1.7 mm
2.5 mm²	14	17.0 mm	9.5 mm	4.1 mm	2.2 mm
4.0 mm²	12	26.5 mm	18.5 mm	5.0 mm	2.8 mm
6.0 mm²	10	27.0 mm	18.0 mm	6.1 mm	3.5 mm
10.0 mm²	7	28.0 mm	19.0 mm	7.6 mm	4.5 mm
16.0 mm²	5	28.5 mm	18.5 mm	8.5 mm	5.8 mm
25.0 mm²	3	30.0 mm	18.5 mm	11.0 mm	7.5 mm
35.0 mm²	2	32.5 mm	18.5 mm	11.9 mm	8.3 mm
50.0 mm²	1/0	34.5 mm	19.0 mm	14.7 mm	10.3 mm

VIABLUE™ crimp sleeves size chart

Size

AWG

1.5 mm²

17.0 mm

9.5 mm

3.2 mm

1.7 mm

2.5 mm²

17.0 mm

9.5 mm

4.1 mm

2.2 mm

4.0 mm²

26.5 mm

18.5 mm

5.0 mm

2.8 mm

6.0 mm²

27.0 mm

18.0 mm

6.1 mm

3.5 mm

10.0 mm²

28.0 mm

19.0 mm

7.6 mm

4.5 mm

16.0 mm²

28.5 mm

18.5 mm

8.5 mm

5.8 mm

25.0 mm²

30.0 mm

18.5 mm

11.0 mm

7.5 mm

35.0 mm²

32.5 mm

18.5 mm

11.9 mm

8.3 mm

50.0 mm²

1/0

34.5 mm

19.0 mm

14.7 mm

10.3 mm
